Old computer's PSU gives useful parts for antennas

Antentop is FREE e-magazine devoted to Antennas and Amateur Radio an

Special page devoted to

Old computer's PSU gives useful parts for antennas

Custom Search

 ANTENTOP- 02- 2003, # 003 Old computer's PSU -                 Smoothly to increase the d.c voltage up to the level, when the bulb has the same glow that this one has had at the RF current. -                 Fix the d.c voltage on PSU's meter. -                 In this case we make a decision, the d.c voltage has the same level like that RF voltage across the bulb. -                 Hence it is possible to calculate going from the transmitter into the RF transformer power. The power is:   P = V2/R,   Where: P- a power, going to the transformer, V- an RF voltage across input winding, R- a resistance of input winding.   We know both the dissipated power at the load and the power going into the input winding. So, it is possible to find the efficiency. Certainly, the indirect method gives us a big error. However it is a very simple method, and even a beginner radio amateur can do it. Note: When the incandescent bulb at the input winding is glowing to its full brightness, the RF power, going to the RF transformer, is close to 10-15 watts. When the incandescent bulb at transformer's load is glowing to a full brightness, the dissipated RF power (in the load) is of 4-9 watts (see Tab. 6). Hence, using the indirect method, and at a full luminescence of load's bulb of 26V/0.12A, it is possible to find values of the efficiency in limits of 40-90 percents. To increase the limits, it need connect a resistor (either the same bulb) in serial together with the bulb at the input winding.     Reference:   1.     Grigorov I.N.: Antenna. Matching and tuning.- Moscow, RadioSoft, 2002. ISBN: 5- 93037- 087- 7 Good Bye Buran and Station MIR Good Fly in our Memory! Page 77
