Antentop is FREE e-magazine devoted to Antennas and Amateur Radio an

Special page devoted to

Some Thoughts on Regenerative Receivers

Custom Search



ANTENTOP- 01- 2010, # 012

Some Thoughts on Regenerative Receivers





Ten-Tec 1253



Credit Line: RigReference.com



Paraset

Note from Credit Line: The PARASET is a small British  "Spy set" transceiver  supplied during the WW2 to the Resistence forces mainly in France, Belgium and Netherland.
It uses 3 metal tubes  :
1) 6SK7 -  Detector
2) 6SK7 - AF Amplifier
3) 6V6 - Cristall Oscillator/P.Amplifier
The range covered from the receiver is  3.2 - 8 MHz on AM and CW modes.
The transmitter is cristall controlled and works on the same receiver range.
The power output is around 5-7 W on CW mode only.
The set were supplied by a 6 Vdc vibrator type PSU.



Credit Line: http://www.qsl.net/ik0moz/paraset_eng.htm



http://www.antentop.org/

Page 70
