Simple QRP TX

for the 40 meters







Antentop is FREE e-magazine devoted to Antennas and Amateur Radio an

Special page devoted to

Simple QRP TX

for the 40 meters





Custom Search



Simple QRP TX for the 40 meters: Credit Line: "U- QRP- C. Reference Book- #3"

At QRP rubric at Antentop 01- 2005 I use stuff from old Soviet QRP magazine published by the U- QRP- C at 1991. It was named "U- QRP- C. Reference Book- #3," you can see its cover at the right. The schematics, which were published there, are very interesting till now.

The simple QRP TX used two FETs was published at "U- QRP- C. Reference Book- #3," page 4. I have done the TX, it worked pretty well!


PDF file, 280 KB (ANTENTOP-01-2005, page: 64)

Download PDF File!

HTML Version

Contents for AntenTop 01- 2005







First page of the
"U- QRP- C. Reference Book- #3'
