ANTENTOP- 01- 2014, # 018

Antenna for 2-meter Band, LPD (433), 70- cm Band and for RMR (446)





Credit Line: Forum from:

radioscanner.ru



By: Igor Vakhreev, RW4HFN



It is very simple antenna that allows works at several frequencies bands with low SWR. The antenna is enough broadband that does not required hold strictly sizes at the design. Figure 1 shows design of the antenna. Made according to the Figure 1 antenna does not require any tuning.



Figure 2 shows impedance of the antenna at the 2- meter Band. Figure 3 shows SWR of the antenna at the 2- meter Band. Figure 4 shows DD of the antenna at the 2- meter Band.





Figure 5 shows impedance of the antenna at the 70-cm Band. Figure 6 shows SWR of the antenna at the 70-cm Band. Figure 7 shows DD of the antenna at the 70-cm Band.



The MMANA file of the Antenna for 2-meter Band, LPD (433), 70- cm Band and for RMR (446) may be loaded at: http: //

www.antentop.org/018/rw4hfn_018.htm







Figure 1 Antenna for 2-meter Band, LPD (433), 70- cm Band and for RMR (446)





www.antentop.org

Page- 64
