ANTENTOP- 01- 2014 # 018

Simple Wire Antenna for All HF- Bands











Vladimir Fursenko, UA6CA





The simple wire antenna works well from 160- to 10 meter. The antenna may be tuned (to needed amateur band) at a shack. Antenna contains only one tuning parts- it is a variable capacitor 10- 200- pF. An inductor (near 3- 5- micro- Henry) is switched in serial with the antenna at the 40- meter Band. Figure 1 shows schematic diagram of the Simple Wire Antenna.



Antenna has wide pass- band that covered all amateur band that is used by the antenna. Good grounding is needed for the antenna. The Simple Wire Antenna was used at station UA6CA with a 4.5- Watt QRP-Transceiver. Antenna shows good result at the operation.





Figure 1 Simple Wire Antenna for All HF- Bands







www.antentop.org

Page- 54





54
