ANTENTOP- 01- 2007  # 009

Inductor Data



Table 5









       L



N

Diameter 50mm



10





17.5



25



37.5



60

2



0.320

0.250

0.200

0.160

0.120

3



0.720

0.560

0.450

0.360

0.270

4



1.280

1.000

0.800

0.640

0.480

5



2.00

1.570

1.250

1.000

0.750

6



2.880

2.250

1.800

1.440

1.075

7



3.920

3.070

2.450

1.960

1.480

8



5.140

4.000

3.200

2.570

1.930

9



6.480

5.050

4.050

3.240

2.430

10



8.000

6.250

5.000

4.000

3.000

12



11.50

9.000

7.200

5.750

4.300

14



16.50

12.30

9.800

7.800

5.900

16



20.50

16.00

12.80

10.25

7.650

18



26.00

20.30

16.30

13.00

9.800

20



32.00

25.00

20.00

16.00

12.00

25



50.00

39.00

31.50

25.00

18.80

30



72.00

56.00

45.00

36.00

27.00

35



98.00

77.00

59.00

49.00

37.00

40



128.0

100.0

80.00

64.00

48.00

45



163.0

127.0

100.0

81.50

61.00

50



200.0

157.0

125.0

100.0

75.00

60



288.0

225.0

180.0

144.0

107.00





Reference 2



F. Burdeynyj, N. Kazanskiy, A. Kamalyagin, K. Shulgin





Spravochnik Korotkovolnovika

(Ham Handbook)

(In Russian)



DOSAAF,

Moscow, 1953



http://www.antentop.org/

Page 96
